Technical specifications for 81305-040-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:81305-040-00
-
Estimated shipping dimensions:19x19x1.5cm
-
Weight:0.1 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Cable length:4.01 m, tolerance ±10%
-
Armor:Without armor
-
Associated Proximitor:81725-01 five-metre Proximitor
-
Electrical system length:5 m combined transducer arrangement
-
Measurement system:14 mm proximity transducer
-
Connector check:Clean, dry and mechanically secure coaxial joint
-
Field modification:Do not splice or shorten
-
Routing:Support without crushing or sharp bends
-
Acceptance:Verify static gap and dynamic response
-
Cable function:Completes the calibrated probe-to-Proximitor signal path
-
Signal path:Coaxial proximity-transducer connection
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 81305-040-00 provides a documented extension cable function within its intended control or monitoring system.
- Provides a documented 4.01 m extension length for a 14 mm system.
- Uses the unarmored 00 cable execution.
- Pairs with the documented 81725-01 five-metre Proximitor arrangement.
- Maintains the calibrated electrical path when installed without field alteration.
Extension-cable length is part of the calibrated transducer system. The probe lead, 4.01 m extension cable and designated Proximitor must be checked together, including connector condition, routing and the channel response.
Important Notice: Verify the complete 81305-040-00 identity, mating hardware and controlled system procedure before installation.
Bently Nevada 81305-040-00 Manuals & Downloads
Bently Nevada 81305-040-00 Technical Reference (PDF)Bently Nevada 81305-040-00 Installation & Commissioning Guide (PDF)
The Technical Reference organizes the exact ordering identity, applicable characteristics and system boundary for this extension cable. The Installation & Commissioning Guide covers identification, pre-installation checks, connections, functional verification and the acceptance record.
14 mm transducer completion
Complete the documented five-metre electrical path between the probe and 81725-01 Proximitor.
Shaft vibration monitoring
Carry the probe signal to the matched signal conditioner.
Axial-position monitoring
Maintain the calibrated path for a qualified 14 mm position measurement.
Legacy-system service
Replace the exact unarmored cable without altering the designed system length.
Use the complete Bently Nevada 81305-040-00 identity and the applicable controlled procedure before work.
1
Verify 81305-040-00 on the cable identification before replacement.
2
Confirm the 4.01 m cable belongs to an 81725-01 five-metre Proximitor arrangement.
3
Do not substitute the armored 01 execution for this unarmored 00 cable without design approval.
4
Keep both coaxial connector surfaces clean and dry.
5
Route the unarmored cable away from abrasion, tension and sharp bends.
6
Support the cable so machine motion does not load either connector.
7
Do not splice, shorten or repair the calibrated cable length in the field.
8
Verify gap voltage, channel OK state and dynamic response after reconnection.
Technical notes
Verify the complete 81305-040-00 identity, mating hardware and controlled system procedure before installation.
FAQ View All FAQ
-
What component is Bently Nevada 81305-040-00?It is a 14 mm proximity-transducer extension cable.
-
What length is Bently Nevada 81305-040-00?The 040 code specifies 4.01 m with a ±10% tolerance.
-
Is Bently Nevada 81305-040-00 armored?No. The 00 suffix identifies the without-armor execution.
-
Which Proximitor is associated with Bently Nevada 81305-040-00?The 040 cable is documented for the 81725-01 five-metre Proximitor arrangement.
-
Can Bently Nevada 81305-040-00 be shortened in the field?No. Its length is part of the calibrated electrical chain.
-
What should be inspected before connecting Bently Nevada 81305-040-00?Check both coaxial joints for cleanliness, dryness and mechanical damage.
-
How should Bently Nevada 81305-040-00 be routed?Support it without crushing, pulling or sharp bends and protect it from abrasion.
-
What confirms commissioning of Bently Nevada 81305-040-00?Verify matched components, gap voltage, stable OK state and approved dynamic response.
