Technical specifications for 330705-02-18-90-02-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330705-02-18-90-02-00
-
Estimated shipping dimensions:21x20x2cm
-
Weight:0.32 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Transducer family:3300 XL 11 mm
-
Probe construction:Reverse mount
-
Mounting thread:3/8-24 UNF
-
Documented fixed code:02-18 reverse-mount geometry
-
Integral lead length:9.0 m
-
Termination:Miniature ClickLoc coaxial connector
-
Agency approval:Not required
-
Nominal linear range:4 mm (160 mil) for the matched 11 mm system
-
Nominal sensitivity:3.94 V/mm (100 mV/mil)
-
System rule:Use the matched 11 mm Proximitor sensor
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330705-02-18-90-02-00 places an 11 mm sensing tip behind the approved probe holder while retaining the documented reverse-mount geometry.
- Uses the 330705 reverse-mount probe construction.
- Provides a 3/8-24 UNF threaded mounting interface.
- Carries a 9.0 m integral lead to a miniature ClickLoc connector.
- Works only as part of the matched 3300 XL 11 mm transducer chain.
The reverse mount probe must remain within its defined transducer or monitoring-system boundary. Confirm the mating hardware, controlled configuration and final signal response before restoring protection.
Important Notice: Verify the complete 330705-02-18-90-02-00 marking, mating interface and controlled channel configuration before installation.
Bently Nevada 330705-02-18-90-02-00 Manuals & Downloads
Bently Nevada 330705-02-18-90-02-00 Technical Reference (PDF)Bently Nevada 330705-02-18-90-02-00 Installation & Commissioning Guide (PDF)The Technical Reference contains selected manufacturer pages for the documented product family, or a dedicated technical reference when a clean source file is unavailable. The installation guide covers identification, installation checks, functional verification and the acceptance record.
Differential expansion
Measure qualified long-range shaft or rotor displacement.
Axial position
Monitor shaft-position change where the 4 mm system range is required.
Radial vibration
Measure relative shaft vibration with the approved 11 mm target geometry.
Reverse-mount installation
Fit the probe from behind a suitable bracket or housing assembly.
Before installing Bently Nevada 330705-02-18-90-02-00, verify the complete nameplate identity, the mating interface and the controlled system configuration.
1
Confirm the complete 330705-02-18-90-02-00 label before installation.
2
Verify the 3/8-24 reverse-mount holder and probe-tip clearance.
3
Use only the matched 3300 XL 11 mm signal conditioner.
4
Route the 9 m lead without tension, sharp bends or abrasion.
5
Keep the miniature coaxial connector clean and fully engaged.
6
Maintain the required target material, diameter and side-view clearance.
7
Set the working gap from the matched 11 mm system response.
8
Verify gap voltage, full expected travel and channel alarms before release.
Technical notes
Verify the complete 330705-02-18-90-02-00 marking, mating interface and controlled channel configuration before installation.
FAQ View All FAQ
-
Which family contains Bently Nevada 330705-02-18-90-02-00?It belongs to the 3300 XL 11 mm proximity-transducer system.
-
How is Bently Nevada 330705-02-18-90-02-00 mounted?It is a reverse-mount probe with 3/8-24 UNF threads.
-
Which lead length is supplied on Bently Nevada 330705-02-18-90-02-00?The selected integral lead length is 9.0 m.
-
Which connector terminates Bently Nevada 330705-02-18-90-02-00?It uses a miniature ClickLoc coaxial connector.
-
What nominal range belongs to the matched Bently Nevada 330705-02-18-90-02-00 system?The 3300 XL 11 mm system provides a nominal 4 mm linear range.
-
Which sensitivity applies to the matched Bently Nevada 330705-02-18-90-02-00 chain?The nominal system sensitivity is 3.94 V/mm.
-
Can Bently Nevada 330705-02-18-90-02-00 use an 8 mm Proximitor sensor?No. It requires the matched 3300 XL 11 mm signal conditioner.
-
What commissioning travel check applies to Bently Nevada 330705-02-18-90-02-00?Verify static gap, expected machine travel, channel scaling and alarm behavior.
