      330106-05-30-05-02-00

      3300 XL 8 mm Metric Reverse-Mount Proximity Probe
      In Stock
      Ships by Wednesday, September 23
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330106-05-30-05-02-00 is a metric reverse-mount 3300 XL 8 mm proximity probe. It converts shaft-to-probe displacement into the electrical input used by a matched Proximitor Sensor and machinery-protection channel.

      Ask our team:

      Get a quick price for： 330106-05-30-05-02-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330106-05-30-05-02-00

      Technical specifications for 330106-05-30-05-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330106-05-30-05-02-00
      • Estimated shipping dimensions:
        1.2x1x69cm
      • Weight:
        0.05 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe series:
        3300 XL 8 mm
      • Mounting execution:
        Reverse mount
      • Probe body thread:
        M10 x 1
      • Unthreaded length:
        50 mm
      • Overall case length:
        300 mm
      • Total probe length:
        0.5 m
      • Connector:
        Miniature coaxial ClickLoc
      • Cable option:
        Standard cable
      • Agency approval option:
        Not required
      • Probe tip material:
        Polyphenylene sulfide (PPS)
      • Probe case material:
        AISI 303 or 304 stainless steel
      • Nominal probe DC resistance:
        7.45 +/- 0.50 Ohm
      • Probe case-to-lead tensile rating:
        330 N maximum
      • Connector tensile rating:
        270 N maximum
      • Minimum cable bend radius:
        25.4 mm
      • Standard probe temperature:
        -52 to +177 degC
      • Matched-system linear range:
        2 mm
      • Incremental scale factor:
        7.87 V/mm nominal
      • Frequency response:
        0 to 10 kHz, +0/-3 dB
      • Minimum flat target diameter:
        15.2 mm
      • Minimum shaft diameter:
        50.8 mm
      • Recommended shaft diameter:
        76.2 mm
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330106-05-30-05-02-00 is a metric reverse-mount 3300 XL 8 mm proximity probe. It converts shaft-to-probe displacement into the electrical input used by a matched Proximitor Sensor and machinery-protection channel.
      • Places the probe connector and lead on the service side of a reverse-mount sleeve
      • Detects shaft displacement without physical contact
      • Operates as the sensing element of a matched 3300 XL 8 mm transducer loop
      • Supports constrained bearing-housing installations requiring a long metric reverse-mount body

      330106-05-30-05-02-00 installs with 3300 XL reverse-mount sleeve, 3300 XL 8 mm Proximitor Sensor, matched extension cable for the engineered system length, compatible Bently Nevada monitor channel in an engineered 3300 XL 8 mm Proximity Transducer System configuration.

      The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this 3300 xl 8 mm metric reverse-mount proximity probe.

      Important Notice: Confirm the complete 330106-05-30-05-02-00 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.

      Apter Power 330106-05-30-05-02-00 Manuals and Guides
      Apter Power 330106-05-30-05-02-00 Product Technical Reference PDFBently Nevada 330106-05-30-05-02-00 Official Manual PDF
      The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
      Reverse-mount radial vibration measurementPlaces the probe connector and lead on the service side of a reverse-mount sleeve
      Restricted-access bearing housingDetects shaft displacement without physical contact
      Axial position monitoringOperates as the sensing element of a matched 3300 XL 8 mm transducer loop
      Shaft centerline observationSupports constrained bearing-housing installations requiring a long metric reverse-mount body
      Read the applicable Bently Nevada installation instructions before work. Verify 330106-05-30-05-02-00 and the installed 3300 XL 8 mm Proximity Transducer System configuration.
      1Verify the complete 330106-05-30-05-02-00 marking and reverse-mount sleeve before work.
      2Place the machine and connected protection channel in the approved maintenance state.
      3Prevent the long probe body from contacting the shaft while setting insertion depth.
      4Keep the M10 x 1 thread, PPS tip and sleeve surfaces free from burrs and contamination.
      5Maintain the published cable bend radius and do not load the ClickLoc connector.
      6Match probe, extension cable and Proximitor Sensor to the engineered total system length.
      7Set the static operating gap inside the documented linear region.
      8Prove polarity, dynamic response and alarm action before returning protection service.

      Technical notes

      Technical notes

      Set the reverse-mount sleeve and insertion depth before securing the 300 mm body, then route the 0.5 m lead without loading the ClickLoc termination. Verify the complete system length, static gap and monitor scaling before enabling protection.

      FAQS

      • Why does 330106-05-30-05-02-00 use a reverse-mount construction?
        The reverse-mount execution places the lead connection on the service side of its sleeve for installations where probe access is constrained.
      • What thread and fixed body dimensions identify 330106-05-30-05-02-00?
        The official ordering code specifies an M10 x 1 body with the fixed 05-30 reverse-mount geometry.
      • What cable length is supplied on 330106-05-30-05-02-00?
        Suffix 05 identifies a 0.5 m total probe length.
      • Does 330106-05-30-05-02-00 use FluidLoc cable?
        No. Connector option 02 specifies a miniature ClickLoc coaxial connector with standard cable.
      • Which approval option applies to 330106-05-30-05-02-00?
        The final 00 code means an agency approval option is not required for this execution.
      • How should 330106-05-30-05-02-00 be gapped?
        Set the matched system within its documented linear region while maintaining shaft clearance through the full machine movement range.
      • Can 330106-05-30-05-02-00 be connected to any Proximitor Sensor?
        Use the Proximitor and extension-cable combination specified for the engineered 3300 XL 8 mm system length and target material.
      • What commissioning checks follow replacement of 330106-05-30-05-02-00?
        Verify insertion depth, cable routing, bias voltage, polarity, dynamic response and alarm action before restoring protection.
