      330104-15-23-10-02-00

      Armored Proximity Probe
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      A 1.0 m 3300 XL 8 mm M10 x 1 proximity probe with 150 mm unthreaded length, 230 mm case length, miniature coaxial clickloc without protector and the 00, not required selection.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330104-15-23-10-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330104-15-23-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330104-15-23-10-02-00
      • Estimated shipping dimensions:
        26.5x28x2cm
      • Weight:
        0.62 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        330104
      • Probe case thread:
        M10 x 1
      • Unthreaded length:
        150 mm
      • Case length:
        230 mm
      • Total probe length:
        1.0 m
      • Cable construction:
        75 ohm triaxial FEP with stainless-steel armor
      • Connector selection:
        Miniature coaxial ClickLoc without protector
      • Approval selection:
        00, not required
      • Linear range:
        2.0 mm (80 mils)
      • Recommended gap:
        About 1.27 mm at -9 Vdc
      • Scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 to 10 kHz
      • Probe tip:
        8.0 mm PPS
      • Minimum bend radius:
        25.4 mm
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330104-15-23-10-02-00 is a 3300 XL 8 mm M10 x 1 armored probe with 230 mm case length and 1.0 m total probe length.
      • M10 x 1 case thread
      • 150 mm unthreaded length
      • 230 mm case length
      • Miniature coaxial ClickLoc without protector

      This armored probe is the sensing end of a matched 3300 XL 8 mm transducer chain. Pair its probe-plus-extension length with the selected Proximitor Sensor, preserve the documented connector arrangement and verify the target material before calibration.

      Important Notice: Verify the complete 330104-15-23-10-02-00 marking, matched electrical length, connector selection and 00, not required record before installation; do not borrow another suffix.

      Bently Nevada 330104-15-23-10-02-00 Manuals & Downloads
      Bently Nevada 330104-15-23-10-02-00 Manufacturer Datasheet Excerpt (PDF)Bently Nevada 330104-15-23-10-02-00 Installation & Commissioning Guide (PDF)

      The manufacturer excerpt preserves selected original datasheet pages and is not the complete publication. The installation guide is an Apter Power field workflow for controlled restoration and commissioning.

      Radial vibration
      Measures shaft motion in a correctly engineered 3300 XL 8 mm channel.
      Axial position
      Supports static position measurement within the documented linear range.
      Phase reference
      Can form the probe end of a compatible phase-reference channel.
      Exact suffix renewal
      Restores the 330104-15-23-10-02-00 execution without borrowing another probe geometry.
      Bently Nevada 330104-15-23-10-02-00 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Read the full 330104-15-23-10-02-00 marking before removing the installed probe.
      2
      Record probe gap, target material, runout and monitor configuration before service.
      3
      Confirm M10 x 1, 150 mm unthreaded length and 230 mm case length.
      4
      Keep the cable route within the 25.4 mm minimum bend radius and protect the clickloc connector.
      5
      Join clean mating connectors finger tight; 0.565 N m is a maximum limit, not a tightening target.
      6
      Match probe-plus-extension length to the Proximitor Sensor electrical-length selection.
      7
      Restore the documented gap voltage and verify static and dynamic response before release.
      8
      Confirm the ordered 00, not required marking instead of assigning approval from the family name.

      Technical notes

      For 330104-15-23-10-02-00, retain the exact ordered suffix, installed measurement-chain record and witnessed acceptance result. Return the channel to service only after the model-specific electrical and mechanical checks pass.

      FAQ View All FAQ

      • How does Bently Nevada 330104-15-23-10-02-00 function within a matched 3300 XL 8 mm measurement chain?
        Bently Nevada 330104-15-23-10-02-00 is the armored M10 x 1 probe at the sensing end of a matched probe, extension cable and Proximitor Sensor chain.
      • Why must a replacement for Bently Nevada 330104-15-23-10-02-00 retain the armored M10 x 1 execution?
        The 330104 prefix specifies the stainless-steel-armored M10 x 1 probe construction, so an unarmored or differently threaded probe would not preserve the ordered mechanical execution.
      • What mounting clearance is required by the 150 mm unthreaded section and 230 mm case of Bently Nevada 330104-15-23-10-02-00?
        The mounting arrangement must accommodate the documented 150 mm unthreaded length and 230 mm case length without forcing, bending or substituting a shorter geometry.
      • How is the 1.0 m lead of Bently Nevada 330104-15-23-10-02-00 used when selecting its extension cable and Proximitor Sensor?
        The probe lead contributes 1.0 m to the channel electrical length; the probe plus extension cable must equal the total length selected for the Proximitor Sensor.
      • Which connector arrangement belongs to Bently Nevada 330104-15-23-10-02-00?
        This suffix uses a miniature coaxial ClickLoc connector without a connector protector, so the mating extension hardware must preserve that interface.
      • What output checks apply after Bently Nevada 330104-15-23-10-02-00 is gapped near 1.27 mm at -9 Vdc?
        The installed matched system should be checked for the nominal 7.87 V/mm scale factor and a usable response across the documented 2.0 mm linear range.
      • Which signal bandwidth is documented for a channel built with Bently Nevada 330104-15-23-10-02-00?
        The 3300 XL 8 mm system specification lists a 0 to 10 kHz frequency response when the probe is used in the correctly matched transducer system.
      • What does the 00 approval suffix mean when accepting Bently Nevada 330104-15-23-10-02-00 after installation?
        The 00 suffix identifies the not-required approval selection; acceptance should use the exact ordered marking and must not assign an approval belonging to another family member.
