      330101-30-63-10-02-CN

      Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330101-30-63-10-02-CN is an unarmored 3300 XL 8 mm proximity probe with a 3/8-24 UNF mounting thread, 3.0-inch unthreaded section, 6.3-inch case and 1.0 m standard lead. The -02 connection uses a miniature coaxial ClickLoc connector; the CN approval option must match the installation certification.

      Ask our team:

      Get a quick price for： 330101-30-63-10-02-CN
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330101-30-63-10-02-CN

      Technical specifications for 330101-30-63-10-02-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330101-30-63-10-02-CN
      • Estimated shipping dimensions:
        ​23x23x2cm
      • Weight:
        0.12 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        3300 XL 8 mm
      • Mounting thread:
        3/8-24 UNF
      • Armor:
        Without armor
      • Unthreaded length:
        3.0 in
      • Overall case length:
        6.3 in
      • Total probe length:
        1.0 m
      • Connector:
        Miniature coaxial ClickLoc
      • Cable type:
        Standard cable
      • Connector protector option:
        Not included in -02
      • Approval option:
        CN - hazardous-area country-specific ordering option
      • Probe DC resistance:
        7.59 ± 0.50 ohm, center conductor to outer conductor
      • Standard probe temperature:
        -52°C to +177°C; pressure-seal caution below -34°C
      • Probe case material:
        AISI 303 or 304 stainless steel
      • Probe tip material:
        Polyphenylene sulfide (PPS)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330101-30-63-10-02-CN is an unarmored 3300 XL 8 mm proximity probe with a 3/8-24 UNF mounting thread, 3.0-inch unthreaded section, 6.3-inch case and 1.0 m standard lead. The -02 connection uses a miniature coaxial ClickLoc connector; the CN approval option must match the installation certification.
      • Supports static gap and dynamic displacement sensing
      • Secures the lead through the CableLoc retention design
      • Uses the TipLoc molded coil-to-tip construction
      • Allows connector protection to be fitted separately

      The probe operates with a correctly matched 3300 XL extension cable and Proximitor Sensor, or in the documented probe-only one-meter arrangement. The transducer output represents the distance to a conductive target.

      Important Notice: Preserve the complete CN marking, mounting geometry, cable arrangement and target calibration. Do not substitute another approval option or assume that standard cable provides FluidLoc containment.

      Bently Nevada 330101-30-63-10-02-CN Manuals & Downloads
      330101-30-63-10-02-CN Technical Reference (PDF)330101-30-63-10-02-CN Manufacturer Datasheet Excerpt (PDF)

      The first document gives a model-specific technical reference. The second preserves original manufacturer pages 1–6, 9–14, 18–19, 23–25 and 28 from 141194 Rev. AN; it is an excerpt, not the complete datasheet.

      Radial shaft vibration
      Measures dynamic displacement at a fluid-film bearing when installed in a matched 3300 XL transducer chain.
      Axial position sensing
      Provides non-contact position information from the conductive target in the configured monitoring arrangement.
      Phase-reference duty
      Supports an engineered Keyphasor reference arrangement; speed-related use requires the corresponding application review.
      Unarmored probe renewal
      Restores the specific UNF forward-mount position while preserving its cable route, exposed section and CN marking.
      Read the Bently Nevada transducer instructions before work. Verify 330101-30-63-10-02-CN, the CN marking, conductive target and complete sensing chain before replacement or commissioning.
      1
      Confirm the UNF forward-mount position and retain the complete CN approval marking.
      2
      Place the monitored machine in its approved maintenance state before probe work.
      3
      Keep the conductive target and installed calibration basis unchanged.
      4
      Protect the unarmored cable from damage along its existing route.
      5
      Match total probe-plus-extension length to the Proximitor Sensor selection.
      6
      Finger-tighten the two XL ClickLoc connectors until the locking connection engages.
      7
      Provide connector environmental protection; -02 does not include a protector.
      8
      Verify the final static gap and dynamic monitoring response before release.

      Technical notes

      Technical notes

      Retain the forward-mount geometry and complete CN approval marking. Match the probe lead and extension cable to the Proximitor system length, and verify target-material calibration before commissioning.

      FAQS

      • How does the 30-63 geometry affect a forward-mount replacement?
        The unthreaded section is 3.0 in and the overall case is 6.3 in. Both dimensions belong to the mounting identity; retaining only the thread size does not preserve the installed geometry.
      • Does the CN suffix have the same meaning as approval option 05?
        No. CN is a country-specific hazardous-area ordering option, while 05 denotes the listed CSA, ATEX and IECEx approval option. The installed certification and product marking determine the required option.
      • Is a connector protector included in this -02 build?
        The -02 option supplies the miniature coaxial ClickLoc connector with standard cable, without a factory-installed connector protector. A separate protector can be fitted to improve environmental protection.
      • Will this standard cable stop liquid migrating through its interior?
        That containment function belongs to the optional FluidLoc cable construction. The standard cable specified by -02 must not be treated as a FluidLoc lead.
      • Which resistance check applies to this lead before connection?
        Probe resistance from center conductor to outer conductor is 7.59 ± 0.50 ohm for the 1.0 m lead. This is a probe continuity reference, not the resistance of an added extension cable.
