Technical specifications for 16925-20
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:16925-20
-
Estimated shipping dimensions:23x23x3cm
-
Weight:0.25 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Input Channels:8
-
Output Channels:4
-
Certifications:CE, RoHS compliant, applicable CSA/ATEX
-
Conductor Type:Stranded copper wire, shielded, silver-plated copper on some models
-
Connector Type:Factory-molded keyed connector
-
Wire Size:22 AWG
-
Conductor Count:3-conductor
-
Operating Temp:-20°C to +80°C (or customized per specific application environments)
-
Voltage Rating:Typically 300V / 600V (subject to specific standards)
Information
Overview
Manuals
Common Applications
Product Precautions
The 16925-20 is a 35mm DIN rail mounting bracket/isolator specifically designed for Bently Nevada sensor systems (such as 330400 accelerometer interface modules or 3300 XL proximity probe proximitors). Its primary purpose is to securely fix the signal conditioning modules to standard industrial rails. Constructed from high-strength engineering plastic, it provides electrical isolation between the module case and the metal rail, effectively eliminating ground loop interference in the field.
- Superior Electrical Isolation & Noise Reduction
- Standardization & High Compatibility
- Easy Snap-on Maintenance
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 16925-20 Interconnect Cable, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Power Generation
Supports signal conditioners for steam turbines and generators, ensuring signals are free from EMI in high-power plant environments.
Oil & Gas
Installed in cabinets for centrifugal compressors and large pump sets, providing physical support for critical F&G and machinery protection.
Petrochemical
Used for mounting vibration monitoring modules for ethylene units, extruders, and process pumps, providing essential electrical isolation.
Water & Wastewater
Secures vibration sensor modules for motors of large water supply pumps and wastewater treatment blowers.
Air Separation
Monitoring overspeed protection and vibration levels of large air separation compressors and turbo-expanders.
Pulp & Paper
Monitors signal transmission modules for high-frequency vibrations in paper machine drying sections and drive motors.
When using the 16925-20 mounting bracket, the focus must be on maintaining both physical stability and electrical isolation. It is essential to securely bolt the Proximitor to the bracket and ensure the plastic clips are firmly locked onto the 35mm DIN rail to prevent module loosening caused by industrial vibrations. To preserve critical ground isolation and eliminate interference, never use damaged or carbonized brackets. Additionally, during removal in extreme temperature environments, handle the spring clips with care to prevent the engineering plastic from cracking due to brittleness.
FAQ View All FAQ
-
What is 16925-20?The 16925-20 is a rail mounting isolator/bracket specifically designed for Bently Nevada Proximitors.
-
What is the primary function of 16925-20?Its core functions are physical support and electrical isolation.
-
How to install the 16925-20?First, bolt the Proximitor onto the isolator bracket, then snap the entire assembly onto a standard 35mm DIN rail. It can be done without complex tools.
-
Which Proximitor models are compatible with 16925-20?It is primarily compatible with 3300 XL series and earlier 3300 series Proximitors for 5-meter and 9-meter systems.
-
Does 16925-20 support use in hazardous areas?Yes. As a passive mechanical component, it is typically certified with the Proximitor system under ATEX/IECEx for use in hazardous area control cabinets.
