The MC-TAMT03 51309223-175 is a classic low-level analog input field termination component in Honeywell's DCS systems. It primarily serves as a bridge between field sensors and system control cards.
Features an open passive cooling design with no complex logic
Supporting "plug-and-play" upgrades that significantly reduce system downtime
The Process Manager (PM), Advanced Process Manager (APM) and High Performance Process Manager (HPM) are Honeywell’s leading TotalPlant Solution (TPS) system control and data acquisition devices for industrial process applications. They represent a powerful combination of cost-effective Honeywell controllers which can be applied to solve a broad range of industrial process control problems. The PM, APM, and HPM offer highly flexible I/O (input/output) functions for both data monitoring and control. One of the unique features of this family of controllers is its common set of Input/Output Processors (IOPs) and Field Termination Assemblies (FTAs). All IOPs and FTAs are usable by all three controllers (with only minor exceptions).
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Honeywell MC-TAMT03 51309223-175 Multiplexer Thermocouple Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil Refining
Monitoring temperature profiles in fractionation columns to optimize petroleum separation efficiency.
Thermal Power
Collecting thermocouple signals from boiler tubes to monitor for metal overheating.
Ethylene Production
Monitoring cracking furnace outlet temperatures, a critical parameter for chemical reaction control.
Steel & Iron
Used for temperature monitoring of blast furnace hearths and walls to prevent burn-through accidents.
Nuclear Power
Monitoring temperatures in auxiliary systems of steam generators.
Cement Industry
Monitoring bearing and casing temperatures of rotary kilns to prevent mechanical failure.
When wiring, it is essential to maintain strict polarity consistency for thermocouple extension wires and ensure proper shield grounding to eliminate electromagnetic interference on weak signals. Since the board features integrated Cold Junction Compensation (CJC) sensors, it should be installed away from heat sources within the cabinet, with cabinet doors kept closed to maintain a stable ambient reference temperature. Additionally, before replacement, verify that the cable connection to the rear I/O Processor (IOP) is secure to prevent significant signal fluctuations or open-circuit alarms caused by poor contact.
MC-TAMT03 51309223-175 is a Multiplexer Thermocouple
What does the part number 51309223-175 represent?
This is the specific hardware part number, typically corresponding to Low Level Analog Input (LLAI) specifications.
How to connect the MC-TAMT03 51309223-175?
Field instrument wires connect to screw terminals, and the board connects to the I/O card via a dedicated cable.gnals from the field and transmit them to the I/O processor.
Does the MC-TAMT03 51309223-175 have cold junction compensation?
Yes, as a thermocouple input board, it typically includes cold junction reference sensors to ensure accurate temperature measurement.
How many input channels does the MC-TAMT03 51309223-175 support?
This FTA typically supports 16 analog input channels.
