      DC-TCF901 51307593-176

      DC-TCF901 Control Firewall IOTA
      In Stock
      Ships by Friday, October 2
      Fast Shipping Available

      Product Describe：

      Honeywell DC-TCF901 51307593-176 is a Series C Mark II Control Firewall IOTA. It provides eight in-cabinet FTE downlinks, one supervisory uplink and the documented 24 VDC distribution for the installed CC-PCF901 module.

      Ask our team:

      Get a quick price for： DC-TCF901 51307593-176
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Alternative names Technical notes FAQ

      Technical specifications for DC-TCF901 51307593-176

      Technical specifications for DC-TCF901 51307593-176

      • Manufacturer:
        Honeywell
      • Product Category:
        DCS System
      • Spare Part Number:
        51307593-176
      • Estimated shipping dimensions:
        22x12x5.5cm
      • Weight:
        0.22 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product type:
        Control Firewall IOTA
      • IOTA model:
        DC-TCF901
      • Manufacturer item number:
        51307593-176
      • Series:
        Series C Mark II
      • Mounted module:
        CC-PCF901 Control Firewall
      • FTE downlinks:
        8 in-cabinet ports
      • Supervisory uplink:
        1 port
      • Total FTE connections:
        9
      • Power distribution:
        24 V DC
      • PWB execution:
        Coated
      • Fiber module options:
        CC-FSMX01 and CC-FMMX01 where documented
      • Network role:
        Control Firewall FTE segment termination
      • Commissioning scope:
        Port mapping, power, redundancy, fiber/copper media and FTE health
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Honeywell DC-TCF901 51307593-176 provides termination, power distribution and FTE connection for a Series C Control Firewall.
      • Eight in-cabinet FTE downlinks
      • One supervisory FTE uplink
      • 24 VDC distribution
      • Coated Series C Mark II IOTA

      The IOTA remains matched to the documented CC-PCF901 module, cabinet power and approved FTE topology. Commissioning restores every port and verifies supervised communication through the Control Firewall.

      Important Notice: Confirm DC-TCF901 51307593-176, CC-PCF901 seating, 24 VDC distribution, FTE port mapping, media modules and acceptance evidence before release.

      DC-TCF901 51307593-176 Manuals & Downloads

      These documents are different: the first consolidates verified product and system data; the second provides model-specific installation checks, commissioning steps and acceptance guidance.

      C300 control-network firewall
      Terminates the installed Control Firewall in a Series C cabinet.
      FTE cabinet segmentation
      Provides approved downlinks and supervisory uplink connectivity.
      Copper or fiber network path
      Supports the documented media modules and cabling architecture.
      Control Firewall replacement
      Restores port mapping, power distribution and FTE diagnostics.
      Read the applicable Honeywell installation instructions before work. Verify DC-TCF901 51307593-176, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
      1
      Confirm DC-TCF901 and item number 51307593-176 on the IOTA record.
      2
      Place the C300 and affected FTE paths in the approved maintenance state.
      3
      Record all eight downlinks, the supervisory uplink and installed media modules.
      4
      Isolate 24 VDC and network paths using the documented Control Firewall procedure.
      5
      Verify CC-PCF901 seating and every copper or fiber connection.
      6
      Restore power distribution, FTE cabling and configured topology.
      7
      Review port, link, redundancy and Control Firewall diagnostics.
      8
      Confirm supervised communication through every required path before release.

      Alternative Names

      Alternative Names

      DC-TCF901; 51307593-176

      Technical notes

      Technical notes

      Install DC-TCF901 51307593-176 only in the documented Experion PKS Control Firewall position and preserve its exact wiring, interfaces and configuration. After controlled energization, verify diagnostics and termination, power distribution and FTE connection for a Series C Control Firewall before release.

      FAQS

      • Which module mounts on DC-TCF901 51307593-176?
        The documented module is the CC-PCF901 Control Firewall.
      • How many in-cabinet FTE downlinks does DC-TCF901 51307593-176 provide?
        It provides eight in-cabinet FTE downlinks.
      • How many supervisory uplinks does DC-TCF901 51307593-176 provide?
        It provides one supervisory uplink.
      • What is the total documented FTE connection count for DC-TCF901 51307593-176?
        The IOTA provides nine documented FTE connections.
      • Which power distribution is provided by DC-TCF901 51307593-176?
        It provides the documented 24 V DC distribution for the Control Firewall.
      • Which fiber modules may be used with DC-TCF901 51307593-176?
        CC-FSMX01 and CC-FMMX01 are documented where the selected topology requires them.
      • Why must the port map be recorded before replacing DC-TCF901 51307593-176?
        Each downlink and uplink must return to its approved FTE path.
      • Which acceptance evidence is required for DC-TCF901 51307593-176?
        Confirm power, port links, redundancy, diagnostics and supervised communication through every required path.
