      Bently Nevada 330173-00-03-10-02-00
      Bently Nevada 330173-00-03-10-02-00
      Bently Nevada 330173-00-03-10-02-00
      Bently Nevada 330173-00-03-10-02-00
      Bently Nevada 330173-00-03-10-02-00
      Bently Nevada 330173-00-03-10-02-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330173-00-03-10-02-00

      5 mm Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330173-00-03-10-02-00 is an unarmored M8 x 1 metric probe in the 3300 5 mm proximity transducer family. With a compatible 3300 XL extension cable and Proximitor Sensor, it measures machine vibration and position without contact.

      Ask our team:

      Get a quick price for： 330173-00-03-10-02-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330173-00-03-10-02-00

      Technical specifications for 330173-00-03-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330173-00-03-10-02-00
      • Estimated shipping dimensions:
        115.5x1.5x1.5cm
      • Weight:
        0.04 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Component:
        3300 5 mm Proximity Probe
      • Thread:
        M8 x 1 metric
      • Cable Armor:
        None
      • Connector:
        Miniature coaxial ClickLoc, standard cable
      • Agency Approval Option:
        00 (no additional approval specified)
      • Probe Tip Material:
        Polyphenylene sulfide (PPS)
      • Probe Case Material:
        AISI 303 or 304 stainless steel
      • Probe Cable:
        75-ohm triaxial, FEP-insulated
      • Probe Temperature Range:
        -35 to +177 °C
      • Matched-System Linear Range:
        2 mm (probe + XL cable + Proximitor Sensor)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330173-00-03-10-02-00 is an unarmored M8 x 1 metric proximity probe in the 3300 5 mm family. With a compatible 3300 XL extension cable and Proximitor Sensor, its transducer system measures shaft position and vibration without contact.
      • Metric probe: M8 x 1 case without armor.
      • ClickLoc connection: standard miniature coaxial connector.
      • Probe construction: PPS tip and stainless-steel case.
      • Matched system: static position and dynamic vibration output.

      The system can also support Keyphasor and speed applications when configured for the machine and monitoring channel.

      Important Notice: Confirm the complete 330173-00-03-10-02-00 marking, target material and matched transducer components before installation or replacement.

      Bently Nevada 330173-00-03-10-02-00 Manuals and Downloads

      Bently Nevada 330173-00-03-10-02-00 Technical Reference (PDF)Bently Nevada 330173-00-03-10-02-00 Installation & Commissioning Guide (PDF)

      Important Notice: The first document covers the exact-model probe and matched-system specifications from the cited manufacturer datasheet; the second is an Apter Power field checklist. Verify the installed system and current manufacturer instructions before work.

      Bently Nevada 330173-00-03-10-02-00 serves a matched noncontact transducer chain in the following manufacturer-documented measurement roles.
      Shaft VibrationNoncontact dynamic vibration measurement on fluid-film bearing machinery using the matched transducer system.
      Shaft PositionStatic position monitoring from the system output that follows conductive-target gap.
      Keyphasor ReferenceReference measurement on an approved machine installation and monitoring channel.
      Speed MeasurementSpeed sensing where the application and monitor configuration have been engineered for it.
      Before installing Bently Nevada 330173-00-03-10-02-00, confirm the complete unarmored metric probe identity, compatible transducer chain and approved plant work procedure.
      1
      Record the full 330173-00-03-10-02-00 nameplate and M8 x 1 mounting position.
      2
      Isolate the channel and machine interface under the plant-approved procedure.
      3
      Inspect the PPS tip, stainless-steel case and conductive target before mounting.
      4
      Route the unarmored standard probe cable away from abrasion, strain and pinch points.
      5
      Mate the ClickLoc connector finger-tight until the connection clicks.
      6
      Use the specified connector protection and verify the compatible 3300 XL extension cable.
      7
      Confirm Proximitor Sensor calibration, monitor input and approved target gap.
      8
      Record static output and authorized functional response before release.

      Technical notes

      Technical notes

      Bently Nevada 330173-00-03-10-02-00 is a 3300 5 mm metric M8 x 1 proximity probe without armor. Use it with a compatible 3300 XL extension cable and Proximitor Sensor; the published linear measurement range applies to the complete system. Source: Bently Nevada 3300 5 mm Transducer System Datasheet, 172036 Rev. T.

      FAQS

      • What is 330173-00-03-10-02-00?
        It is a metric M8 x 1, unarmored 3300 5 mm proximity probe.
      • Is the sensing range of 330173-00-03-10-02-00 equal to 5 mm?
        No. The 5 mm names the probe family; the matched 3300 system has a specified 2 mm linear measurement range under the stated conditions.
      • What probe temperature range applies to 330173-00-03-10-02-00?
        The manufacturer lists -35 to +177 °C for the probe; the cable and Proximitor Sensor have separate limits.
      • Which connector does 330173-00-03-10-02-00 use?
        The 02 connector option is a miniature coaxial ClickLoc connector with standard cable and no connector protector.
      • Can 330173-00-03-10-02-00 work alone?
        No. A compatible 3300 XL extension cable and Proximitor Sensor complete the transducer system.
      • What tip and case materials are specified for 330173-00-03-10-02-00?
        The 3300 5 mm probe family uses a PPS tip and an AISI 303 or 304 stainless-steel case.
      • Does 330173-00-03-10-02-00 include cable armor?
        No. The 330173 family is the metric M8 x 1 version without armor; 330174 is the armored metric family.
