      330854-040-24-05

      Extension Cable
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330854-040-24-05 is a 4.0 m high-temperature FluidLoc extension cable for the 3300 XL 25 mm proximity transducer system. It joins a compatible 25 mm probe to the matching Proximitor Sensor in a documented 5 m system.

      Ask our team:

      Get a quick price for： 330854-040-24-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330854-040-24-05

      Technical specifications for 330854-040-24-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330854-040-24-05
      • Estimated shipping dimensions:
        22.5x1.2x24cm
      • Weight:
        0.16 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Component:
        3300 XL 25 mm extension cable
      • Cable length option 040:
        4.0 m
      • Armor and cable option 24:
        High-temperature FluidLoc
      • Cable armoring:
        Unarmored
      • Agency approval option 05:
        Multiple approvals
      • Cable construction:
        75 ohm triaxial, PFA insulated FluidLoc
      • 4 m core resistance:
        1.0 ± 0.25 ohm
      • 4 m coaxial resistance:
        0.3 ± 0.1 ohm
      • Typical cable capacitance:
        69.9 pF/m
      • Cable operating temperature:
        -35 to +200 deg C
      • Minimum bend radius:
        25.4 mm
      • Connector mating torque:
        Finger tight; 0.565 N m maximum
      • Connector joint tensile rating:
        270 N maximum
      • Matched 5 m chain:
        1 m probe plus 4 m extension cable
      • System function:
        25 mm differential-expansion measurement chain
      • Connector type:
        High-temperature ClickLoc
      • Installed-system pairing:
        3300 XL 25 mm probe and Proximitor Sensor
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330854-040-24-05 is a 4.0 m high-temperature FluidLoc extension cable for a matched 3300 XL 25 mm proximity transducer system.
      • Exact article identity: 330854-040-24-05
      • Code 040 selects the 4.0 m cable length
      • Code 24 selects high-temperature FluidLoc cable without armor
      • Code 05 selects multiple agency approvals

      The cable joins a compatible 25 mm probe to its matching Proximitor Sensor. A documented 1.0 m probe plus this 4.0 m cable forms a 5.0 m transducer chain.

      Important Notice: Confirm the complete marking, 25 mm component family, installed cable route and matched system configuration before work.

      Bently Nevada 330854-040-24-05 Manuals & Downloads
      Bently Nevada 330854-040-24-05 Technical Reference (PDF)Bently Nevada 330854-040-24-05 Installation & Commissioning Guide (PDF)

      These documents serve different purposes: the first records exact cable and matched-system data; the second covers installation checks, commissioning and acceptance.

      25 mm differential-expansion chainConnect 330854-040-24-05 between the documented 25 mm probe and matching Proximitor while retaining the selected 5 m system length.
      High-temperature cable routeUse the code-24 execution where the approved 25 mm installation calls for a high-temperature FluidLoc extension cable.
      Four-meter cable replacementReplace only the documented 4.0 m cable execution and preserve the installed probe and Proximitor family.
      Controlled sensor commissioningVerify continuity, connector fit, cable routing and channel response before returning the monitored machine to service.
      Before work, confirm 330854-040-24-05, the installed 3300 XL 25 mm chain and the approved machine state.
      1
      Confirm the complete 330854-040-24-05 marking and the installed 25 mm differential-expansion chain before work.
      2
      Place the connected machine and monitor channel in the approved maintenance state.
      3
      Record probe, cable, Proximitor and 5 m system configuration before removal.
      4
      Isolate documented power and field energy; use ESD controls where required.
      5
      Inspect the 4.0 m high-temperature FluidLoc cable and connector condition before installation.
      6
      Preserve the approved bend radius and connector torque along the cable route.
      7
      Restore keyed connections and verify continuity against the accepted record.
      8
      Prove the configured 25 mm channel and controlled monitor response before release.

      Technical notes

      Technical notes

      The 24 option is a high-temperature FluidLoc cable without the optional armor; 05 specifies multiple agency approvals. Confirm the 25 mm probe-plus-extension length and protect the high-temperature ClickLoc joints before commissioning.

      FAQS

      • How does option 040 set the 330854-040-24-05 system length?
        It selects a 4.0 m extension. Combined with a 1.0 m 3300 XL 25 mm probe, it forms the 5 m cable-and-probe length required by the matching Proximitor Sensor.
      • Is the 24 cable option on 330854-040-24-05 armored?
        No. Code 24 is high-temperature FluidLoc cable; the separate 25 option adds stainless-steel armor. Match the installed route and protection requirement before substitution.
      • What does the 05 suffix select on 330854-040-24-05?
        The 05 agency-approval option specifies multiple approvals. It does not change the 040 cable length or 24 cable construction.
      • Can 330854-040-24-05 replace an 8 mm or 11 mm extension cable?
        No. The 330854 family is the extension cable for the 3300 XL 25 mm transducer chain; the installed probe, cable and Proximitor must be matched as one 25 mm system.
      • Which resistance readings apply to isolated 330854-040-24-05?
        The published 4 m cable readings are 1.0 ± 0.25 ohm core-to-core and 0.3 ± 0.1 ohm coaxial-to-coaxial. Test only after disconnecting the cable from the monitoring circuit.
      • What temperature range applies to the 330854-040-24-05 cable?
        The extension cable operating and storage range is -35 to +200 deg C. Verify the cable route and connectors against that range, without applying a probe-only short-term limit to the cable.
      • How should 330854-040-24-05 high-temperature ClickLoc joints be tightened?
        Mate the connectors finger-tight. The published connector-to-connector maximum is 0.565 N m; avoid over-torque, contamination and tight bends at either joint.
      • Why verify the full 25 mm chain after replacing 330854-040-24-05?
        Differential-expansion performance depends on the matched probe, extension cable and Proximitor. Restore the original 5 m chain and prove the monitored response through the installed verification procedure.
