      330105-02-12-15-02-CN

      Reverse Mount Probe
      In Stock
      Ships by Wednesday, October 7
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330105-02-12-15-02-CN is a 330105 reverse-mount English 3300 XL 8 mm proximity probe for shaft-relative vibration and position measurement. It uses the documented standard ClickLoc connection within a matched probe, cable and Proximitor Sensor chain.

      Ask our team:

      Get a quick price for： 330105-02-12-15-02-CN
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330105-02-12-15-02-CN

      Technical specifications for 330105-02-12-15-02-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330105-02-12-15-02-CN
      • Estimated shipping dimensions:
        21x21x1cm
      • Weight:
        0.05 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • System family:
        3300 XL 8 mm proximity transducer system
      • Probe construction:
        330105 reverse-mount English; unarmored
      • Mounting format:
        3/8-24 UNF
      • Connector option:
        standard ClickLoc connection
      • Approval control:
        CN is retained from the supplied identity and must be verified against the physical approval marking.
      • Calibration target:
        AISI 4140 steel under published conditions
      • Nominal scale factor:
        7.87 V/mm (200 mV/mil) for the matched system
      • Frequency response:
        0 to 10 kHz, +0/-3 dB under published conditions
      • Standard probe temperature rating:
        -52 to +177 deg C
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330105-02-12-15-02-CN is a 330105 reverse-mount English 3300 XL 8 mm proximity probe for shaft-relative vibration and position measurement. It uses the documented standard ClickLoc connection within a matched probe, cable and Proximitor Sensor chain.
      • 330105 reverse-mount English ordering family
      • Unarmored probe construction
      • standard ClickLoc connection
      • Matched 3300 XL 8 mm signal chain

      Apply 330105-02-12-15-02-CN only to an approved 3300 XL 8 mm monitoring loop with the documented target and companion hardware.

      Important Notice: Confirm 330105-02-12-15-02-CN, the installed mounting, connector, approval marking and matched channel before commissioning.

      330105-02-12-15-02-CN Manuals & Downloads
      330105-02-12-15-02-CN Technical Reference (PDF)330105-02-12-15-02-CN Installation & Commissioning Guide (PDF)

      The first document presents model-specific technical and system data. The second provides a separate installation, connection, commissioning and acceptance workflow.

      Radial shaft vibration
      Measures shaft-relative vibration through the approved matched transducer chain.
      Axial position
      Provides static shaft-position input with the approved target and gap.
      Keyphasor reference
      Supports documented phase and speed reference arrangements.
      Machinery protection
      Supplies a compatible Bently Nevada monitor channel with the conditioned proximity signal.
      Read the applicable Bently Nevada instructions before work. Verify Bently Nevada 330105-02-12-15-02-CN and the installed system configuration before commissioning.
      1
      Verify the complete 330105-02-12-15-02-CN marking before work.
      2
      Confirm the 3/8-24 UNF mounting format.
      3
      Protect the standard ClickLoc connection from impact and contamination.
      4
      Keep probe and cable routing isolated from damage and electrical interference.
      5
      Use the documented target material or an approved correction.
      6
      Match the probe, extension cable and Proximitor Sensor as one system.
      7
      Set the static gap only with the current manufacturer procedure.
      8
      Verify polarity, gap voltage and dynamic response before release.

      Technical notes

      Technical notes

      Use 330105-02-12-15-02-CN only in the documented matched 3300 XL 8 mm transducer chain. Verify the exact nameplate, 3/8-24 UNF mounting, standard ClickLoc connection, target material, static gap and channel response before release.

      FAQS

      • What is Bently Nevada 330105-02-12-15-02-CN?
        It is a 330105 reverse-mount English 3300 XL 8 mm proximity probe for a matched non-contacting transducer system.
      • Which mounting format applies to Bently Nevada 330105-02-12-15-02-CN?
        The official ordering family identifies the 3/8-24 UNF mounting format.
      • Is Bently Nevada 330105-02-12-15-02-CN armored?
        The documented probe construction is unarmored.
      • Which connector applies to Bently Nevada 330105-02-12-15-02-CN?
        The ordering code identifies standard ClickLoc connection.
      • How should the approval suffix on Bently Nevada 330105-02-12-15-02-CN be handled?
        CN is retained from the supplied identity and must be verified against the physical approval marking.
      • What target reference applies to Bently Nevada 330105-02-12-15-02-CN?
        Published performance is referenced to the manufacturer-specified AISI 4140 steel target and matched 3300 XL 8 mm chain.
      • What signal performance applies to Bently Nevada 330105-02-12-15-02-CN?
        The matched family publishes a nominal 7.87 V/mm scale factor and a 0 to 10 kHz response under the stated test conditions.
      • What confirms commissioning of Bently Nevada 330105-02-12-15-02-CN?
        Verify the complete marking, compatible cable and Proximitor Sensor, connector condition, static gap, polarity and dynamic channel response.
