      6GK5204-0BA00-2AF2

      Managed IE Switch
      In Stock

      Product Describe：

      6GK52040BA002AF2
      Managed IE Switch
      SCALANCE XF204
      Flat Design
      4x RJ45 Ports
      10/100 Mbps
      Error Signaling Contact with Set Pushbutton
      Redundant Power Supply
      PROFINET IO Device Network Management
      Redundancy Manager Integrated

      Ask our team:

      Get a quick price for： 6GK5204-0BA00-2AF2
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications

      Technical specifications for 6GK5204-0BA00-2AF2

      Technical specifications for 6GK5204-0BA00-2AF2

      • Manufacturer:
        Siemens
      • Product Category:
        PLC Systems
      • Spare Part Number:
        6GK5204-0BA00-2AF2
      • Estimated shipping dimensions:
        7.4x7.2x12.3cm
      • Weight:
        0.28 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Germany
      • Power Connector:
        1 x 4-pin Terminal Block
      • Signal Trigger Connector:
        1 x 2-pin Terminal Block
      • Swap Media Slot:
        C-PLUG
      • Power Supply Voltage:
        2 x 24V DC (18V to 32V)
      • Current Consumption:
        Maximum 160 mA
      • Power Consumption:
        2.64 W
      • Operating Temperature:
        -40°C to +60°C
      • Transport/Storage Temperature:
        -40°C to +70°C
      • Operating Humidity:
        <95% at 25°C, non-condensing
      • Mounting:
        35 mm DIN rail
      • Protection Rating:
        IP20
