      6EC1001-0A

      SIMATIC C1 AND Logic Board
      In Stock
      Ships by Monday, October 26
      Fast Shipping Available

      Product Describe：

      Siemens 6EC1001-0A is a SIMATIC C1 flat assembly containing eleven two-input AND logic elements for hardwired logic functions.

      Ask our team:

      Get a quick price for： 6EC1001-0A
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 6EC1001-0A

      Technical specifications for 6EC1001-0A

      • Manufacturer:
        Siemens
      • Product Category:
        PLC Systems
      • Spare Part Number:
        6EC1001-0A
      • Estimated shipping dimensions:
        10.9x17.9x1.4cm
      • Weight:
        0.1 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Germany
      • Product family:
        SIMATIC C1
      • Assembly form:
        Flat assembly
      • Logic function:
        AND
      • Logic elements:
        11
      • Inputs per element:
        2
      • Catalogue reference:
        E53252-T32-S2
      • No-load current consumption:
        30 mA
      • Net weight:
        0.1 kg
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Siemens 6EC1001-0A concentrates eleven dual-input AND elements on one SIMATIC C1 flat assembly with the catalogue identity E53252-T32-S2.
      • Contains eleven independent AND logic elements.
      • Provides two inputs for each AND element.
      • Uses the E53252-T32-S2 catalogue reference.
      • Draws 30 mA at no load in the documented SIMATIC C1 arrangement.

      The catalogue records a 30 mA no-load current consumption and a 0.1 kg net weight for this execution. Replacement work must therefore preserve the exact board position, edge connection and the original hardwired logic assignment.

      Important Notice: preserve the complete 6EC1001-0A identity, E53252-T32-S2 catalogue reference, connector orientation and every assigned logic path before replacement.

      Siemens 6EC1001-0A Manuals & Downloads
      Siemens 6EC1001-0A Official ST11 Catalogue Excerpt (PDF)Siemens 6EC1001-0A Installation & Commissioning Guide (PDF)

      The documents separate exact product evidence from the field sequence for identity, isolation, installation, verification and controlled handover.

      Hardwired interlocking
      Implements retained two-input AND conditions inside the SIMATIC C1 logic arrangement.
      Sequence control
      Combines paired permissive signals where the original board assignment requires an AND decision.
      Legacy logic maintenance
      Restores the exact flat-assembly identity and edge-connector orientation during cabinet service.
      Logic-path verification
      Allows each of the eleven AND elements to be checked against the retained circuit record.
      Apply these checks to the exact Siemens 6EC1001-0A position before isolation, replacement or release.
      1
      Confirm the complete Siemens 6EC1001-0A marking before work.
      2
      Place every dependent hardwired function in the approved maintenance state.
      3
      Photograph the board position, connector orientation and surrounding assemblies.
      4
      Record the input and output assignment for all eleven AND elements.
      5
      Match the E53252-T32-S2 catalogue identity before installation.
      6
      Restore the edge connection without shifting or borrowing adjacent wiring.
      7
      Review the cabinet supply and every dependent indication after energization.
      8
      Functionally prove all eleven two-input AND paths before release.

      Technical notes

      Technical notes

      Photograph the installed board, connector orientation and each assigned input/output path before removal. After controlled energization, prove all eleven AND functions against the retained logic record.

      FAQS

      • What logic function does Siemens 6EC1001-0A provide?
        It provides eleven hardwired AND logic elements on one SIMATIC C1 flat assembly.
      • How many inputs does each Siemens 6EC1001-0A logic element use?
        Each of the eleven AND elements uses two inputs.
      • Which product family contains Siemens 6EC1001-0A?
        The board belongs to the Siemens SIMATIC C1 assembly family.
      • Which catalogue reference identifies Siemens 6EC1001-0A?
        The catalogue reference is E53252-T32-S2.
      • What no-load current is recorded for Siemens 6EC1001-0A?
        The documented no-load current consumption is 30 mA.
      • What net weight is listed for Siemens 6EC1001-0A?
        The catalogue lists a net weight of 0.1 kg.
      • What should be captured before removing Siemens 6EC1001-0A?
        Capture the board position, connector orientation and input/output assignment for all eleven logic elements.
      • How should Siemens 6EC1001-0A be verified after installation?
        Prove each two-input AND function and confirm every dependent hardwired circuit behaves as recorded.
