MPRC 086349-002

Name: MPRC 086349-002
Brand: ABB
SKU: 086349-002

Measurement Processor Board

In Stock

Ships by Wednesday, September 9

Fast Shipping Available

Product Describe：

ABB AccuRay MPRC 086349-002 is a measurement processor board used in legacy quality-control scanning electronics. It coordinates measurement-processing functions within the assigned AccuRay platform position.

Ask our team:

Phone:
+86 180 3023 5313
E-Mail:
sales13@apterpower.com

Get a quick price for： MPRC 086349-002

Quantity*

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy.

Technical specifications Information Alternative names Technical notes FAQ

Technical specifications for MPRC 086349-002

Manufacturer:

ABB
Product Category:

DCS System
Spare Part Number:

086349-002
Estimated shipping dimensions:

2.5x12.6x39.5cm
Weight:

0.35 kg
Tariff Code:

8537101190
Counliy of origin:

Sweden
Category:

PLCs/Machine Control
Subcategory:

PC Board PLC/Add-On Board
Power Supply:

24V DC
IP Rating:

IP20
Operating Temperature:

-20°C to +60°C

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

ABB MPRC provides the Measurement Processor Board function within ABB AccuRay QCS installations.

Executes measurement-processing tasks
Coordinates the assigned scanner electronics path
Exchanges data with the platform host interface
Provides board-level diagnostic indications for service

MPRC operates with AccuRay scanning platform electronics, host communication path, sensor interface boards, platform power and backplane.
Typical engineered duties include Paper-machine quality measurement, Scanning-frame electronics service, Profile-measurement processing, Legacy AccuRay platform maintenance.

Important Notice: MPRC 086349-002 must be matched by full board number, platform position and connected scanner-electronics configuration.

Apter Power MPRC Manuals and Guides

Important Notice: These are two separate Apter Power documents prepared from product-specific ABB technical information. Confirm the physical nameplate, installed-system requirements and supplied accessories before configuration or installation.

MPRC Paper-machine quality measurement

Executes measurement-processing tasks

MPRC Scanning-frame electronics service

Coordinates the assigned scanner electronics path

MPRC Profile-measurement processing

Exchanges data with the platform host interface

MPRC Legacy AccuRay platform maintenance

Provides board-level diagnostic indications for service

Read the applicable ABB installation instructions before work. Verify MPRC and the installed-system configuration.

Confirm MPRC together with part number 086349-002 before removal.

Shut down the assigned AccuRay scanning electronics under the platform procedure.

Record the board position, connected cables and installed configuration.

Use ESD controls while handling the processor board.

Inspect backplane contacts, connectors and the local cooling path.

Restore the board to the recorded platform position and cable arrangement.

Run platform diagnostics and verify measurement communication after start-up.

Record the installed part, configuration and completed measurement checks.

Alternative Names

086349-002

Technical notes

MPRC 086349-002 service work should preserve its assigned AccuRay processor position, host connection and surrounding measurement electronics. Record cable placement and confirm measurement-system diagnostics after installation.

FAQS

Which identifier distinguishes this MPRC board?

Use the complete part number 086349-002 together with the MPRC designation.
What system role does MPRC perform?

It is the measurement processor board in the assigned legacy AccuRay scanner-electronics position.
How should MPRC cables be controlled during removal?

Label each connector by board position and mating destination before disconnection.
What configuration must be retained for MPRC?

Retain the board-position settings and platform host communication arrangement.
How is MPRC commissioned after installation?

Run the platform start-up diagnostics and verify measurement communication and scanner operation.
What maintenance inspection applies to MPRC?

Inspect backplane contacts, connector seating, cooling path and diagnostic indications.
Can an 086444-series MPRC replace MPRC 086349-002 directly?

No direct substitution should be made without an ABB platform engineering comparison.
What record should follow MPRC replacement?

Record the removed and installed part numbers, board position, configuration and diagnostic results.
