The DSRF182 57310255-AL is designated as an S100 I/O Equipment Frame, classified as a control system accessory. It is identified in the catalog as “DSRF 182 S100 I/O Equipment Frame” and is used within ABB Advant Master process control systems as part of the I/O subrack structure.
S100 I/O Subrack Design
Integrated Supervision Signals
Control System Accessory Structure
The DSRF182 equipment frame is designed as an S100 I/O subrack that includes supervision signals. It provides a mounting structure for I/O modules and supports system monitoring functions, ensuring proper operation and system integrity within control system architectures.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Power Generation
Used for peripheral device connections in power plant control systems, supporting process automation of boilers and turbines, ensuring the accuracy of real-time monitoring data in complex power production environments.
Oil & Gas
In the oil and gas industry's production processes, it serves as a critical interface component managing field data acquisition, ensuring high availability of the control system in challenging environments.
Chemical & Petrochemical
Widely used in chemical production processes, coordinating the processing of large-scale process input and output signals, providing robust hardware communication support for the continuity and process safety of chemical production.
Metals & Mining
Integrated into metal smelting and mining automation control platforms, maintaining the stability of peripheral communication in heavy industrial environments such as dust and vibration.
Pulp & Paper
Used for distributed control in pulp and paper production lines, achieving fully automated monitoring from raw material processing to paper product output, improving the collaborative reliability of various peripheral devices in the pulp and paper process.
Thermal Energy Systems
Suitable for the automated management of ship propulsion systems and offshore platforms, providing robust peripheral interface connections under extreme marine operating conditions .
The DSRF 182 unit serves as a modular hardware frame for the S100 I/O system, providing the physical and electrical backplane required for peripheral communication. It integrates internal signal routing, logic voltage distribution, and diagnostic supervision circuits for the connected subrack. The assembly features dedicated connectors for the S100 I/O bus and supports the integration of various interface boards and terminal units within an Advant Master control architecture, ensuring structured cable management and electromagnetic compatibility.
What is the primary function of the DSRF182 57310255-AL within the ABB system architecture?
The DSRF 182 is a generic peripheral interface unit for MasterView 320 and MasterPiece 200/1 systems. It functions as a MasterView Peripheral Interface within the S100 I/O system framework.
Which specific ABB control systems are compatible with the DSRF182 57310255-AL equipment frame?
This equipment frame is designed for use within the ABB Advant Master Process Control System, specifically supporting MasterView 320 and MasterPiece 200/1 configurations.
What are the electrical supply requirements and internal voltage for the DSRF182 57310255-AL?
The unit operates with a nominal input of 24 V DC, while internal logic voltage is typically maintained between 5.1 V DC and 5.3 V DC via DSSR regulators in the rack.
What are the defined environmental operating limits for the DSRF182 57310255-AL unit?
The equipment is designed to operate in temperatures ranging from 0 to +55 °C and must be protected according to IP20 standards, typically within an industrial cabinet.
Does the DSRF182 57310255-AL include any built-in monitoring or supervision features?
Yes, the DSRF 182 equipment frame for S100 I/O subracks includes supervision signals to monitor the system's operational integrity and peripheral connectivity.
