      DP620 3BHT300016R1

      High-Speed Counter
      In Stock
      Ships by Saturday, October 24
      Fast Shipping Available

      Product Describe：

      ABB DP620 3BHT300016R1 is a five-channel high-speed counter for 5 V or 24 V DC input signals at rates below 100 kHz.

      Ask our team:

      Get a quick price for： DP620 3BHT300016R1
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for DP620 3BHT300016R1

      Technical specifications for DP620 3BHT300016R1

      • Manufacturer:
        ABB
      • Product Category:
        DCS System
      • Spare Part Number:
        3BHT300016R1
      • Estimated shipping dimensions:
        3.8x26x27.1cm
      • Weight:
        1.42 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Sweden
      • ABB type designation:
        DP620
      • Counter channels:
        5
      • Input levels:
        5 V or 24 V DC
      • Maximum frequency class:
        Below 100 kHz
      • Per-counter inputs:
        Two counting inputs plus strobe and set inputs
      • Isolation:
        Inputs individually isolated
      • Modes:
        Up, down, frequency, differential, position and speed measurement
      • Manufacturer reference:
        3BHT300016R1
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      ABB DP620 3BHT300016R1 provides five isolated high-speed counter channels for frequency, position, speed and directional counting tasks.
      • Five counter channels
      • 5 V or 24 V DC inputs
      • Below 100 kHz frequency class
      • Multiple count and measurement modes

      Each counter combines two count inputs with strobe and set controls. Electrical level, pulse shape, counter mode, scaling, direction and the controller database configuration must agree with the machine design.

      Important Notice: Verify DP620 3BHT300016R1, input level and selected count mode before connection. A valid pulse frequency alone does not prove correct direction, position or speed scaling.

      ABB DP620 3BHT300016R1 Manuals & Downloads

      ABB DP620 3BHT300016R1 Technical Reference (PDF)ABB DP620 3BHT300016R1 Installation & Commissioning Guide (PDF)

      The technical reference organizes exact characteristics and engineering boundaries. The installation guide focuses on controlled preparation, restoration, commissioning and handover.

      Pulse accumulation
      Counts supported 5 V or 24 V pulse trains for machine totals.
      Frequency measurement
      Converts repetitive field pulses into configured rate values.
      Position and speed feedback
      Processes directional input pairs for motion measurement.
      Exact counter replacement
      Restores mode, scaling and control-input assignments for the DP620 position.
      ABB DP620 3BHT300016R1 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm DP620 and 3BHT300016R1 on the module.
      2
      Place the driven machine and counter signals in a safe maintenance state.
      3
      Record input level, mode, scaling, direction and preset behavior.
      4
      Capture both count inputs plus strobe and set assignments.
      5
      Remove rack and field power before module handling.
      6
      Inspect shields, grounding, pulse-source common and connector condition.
      7
      Restore the approved database and counter parameters.
      8
      Inject controlled pulses and prove count, direction, frequency or speed response.

      Technical notes

      Technical notes

      Retain the exact DP620 3BHT300016R1 identity with its installed configuration and acceptance record. Release the equipment only after model-specific diagnostics and the intended field response have been witnessed.

      FAQS

      • How many counters does ABB DP620 3BHT300016R1 provide?
        It provides five high-speed counter channels.
      • Which electrical levels does ABB DP620 3BHT300016R1 support?
        The module supports 5 V or 24 V DC inputs.
      • What frequency class applies to ABB DP620 3BHT300016R1?
        The pulse-counting frequency is below 100 kHz.
      • Which measurement modes does ABB DP620 3BHT300016R1 support?
        Modes include up, down, frequency, differential, position and speed measurement.
      • What inputs belong to each ABB DP620 3BHT300016R1 counter?
        Each counter uses two count inputs plus strobe and set control inputs.
      • What must be retained before replacing ABB DP620 3BHT300016R1?
        Keep level, mode, scaling, direction, preset, address and terminal records.
      • How should ABB DP620 3BHT300016R1 shielding be checked?
        Use the installed pulse-source and cabinet grounding design; avoid creating a second reference path.
      • How is ABB DP620 3BHT300016R1 commissioned?
        Apply a controlled pulse source and verify count, direction, frequency or motion value against the configured scale.
