The 0G0010.00-090 is a 1-meter I/O bus expansion connection cable for legacy System 2005 and System 2010 PLC series. Utilizing 9-pin D-sub connectors operating on an RS485 physical layer specification, it connects central controller racks with expansion chassis to route high-frequency backplane signals.
Both ends feature rugged 9-pin D-Sub interfaces with metal screw locks
High-density braided shielding suppresses high-frequency EMI from adjacent drives or switchgear
Twisted-pair cores cancel phase noise to guarantee backplane bus signal integrity
Based on the RS485 physical layer specifications, this cable establishes a high-speed serial data link between the main power supply expansion slot and the expansion chassis slave. This hardware mechanism routes synchronized, low-latency serial peripheral bus data to effectively mirror and extend the central CPU's local I/O addressing space to auxiliary racks, eliminating complex multi-protocol fieldbus routing within the local cluster.
During on-site maintenance and emergency troubleshooting for complete production lines such as large-scale papermaking, plastic extrusion, and heavy packaging, this cable serves as the critical electrical link to maintain existing legacy B&R control systems. It eliminates the need for immediate hardware restructuring or full system upgrades, thereby reducing downtime and retrofitting costs. However, due to the 1.0-meter physical length and the hardware constraints of the RS485 electrical layer regarding high-frequency signal attenuation, the system enforces strict limits on the maximum number of cascaded chassis allowed when constructing multi-rack topologies.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
ABB 0G0010.00-090 Expansion Connection Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Plastics & Film Extrusion
Extending the local backplane bus via RS485 to route distributed analog temperature modules, enabling real-time heating zone adjustments for extruder barrels.
Pulp & Paper Mills
Linking the master CPU rack with expansion frames to handle high-density digital feedback from paper web tension sensors, preventing high-speed sheet snapping.
Rubber Compounding & Mixing
Linking the central PLC chassis with expansion slots handling load cell weighing cards, achieving precise, millisecond-level raw material feed synchronization.
Woodworking & CNC Machining
Facilitating local expansion loops to link auxiliary digital output cards, managing precise solenoid timings for cutting, gluing, and polishing stations.
Cement & Material Blending
Connecting expansion baseplates within the same control enclosure via the RS485 physical data layer, reading high-speed pulse trains representing raw material flow.
Environmental Monitoring Stations
Expanding localized PLC architectures to accommodate a high volume of analog emission tracking modules, sending aggregated telemetry back to central controllers.
When operating the B&R 0G0010.00-090 bus expansion cable, it must be plugged or unplugged only under complete system power-off conditions, and the metal screws of the 9-pin D-Sub connectors at both ends must be securely tightened to prevent poor contact caused by severe vibrations.
Due to the 1-meter physical length limit and high-frequency signal attenuation on the RS485 layer, multi-rack topologies must strictly adhere to the official maximum cascading limits, and a dedicated termination resistor card must be installed at the final node to prevent signal reflections from locking up the backplane bus. Additionally, ensure the cable bend radius complies with specifications during routing and keep it far from high-power variable frequency drives (VFDs) to avoid electromagnetic interference.
The B&R 0G0010.00-090 is a 1-meter I/O bus expansion cable for legacy System 2005 and 2010 PLC series. Using 9-pin D-sub connectors on an RS485 physical layer, it bridges central racks with expansion chassis to route backplane bus signals. While an accessory rather than a power supply, it acts as a critical node for hardware extensions.
It is an industrial bus connection cable/connector manufactured by B&R, primarily used for internal I/O bus expansion and hardware connectivity within RS485/PROFIBUS networks.
What type of physical electrical interface does 0G0010.00-090 use?
Its termination integrates a standard 9-pin D-SUB (DB9) connector along with screw terminals for connecting two bus lines.
How to use bus expansion cables like 0G0010.00-090?
Securely attach its 9-pin connector to the bus expansion port of the main rack and link the other end to the expansion I/O rack, establishing electrical communication across the different physical racks.
What underlying physical communication standard does 0G0010.00-090 operate on?
It operates based on the RS485 differential signaling standard, supporting industrial fieldbus protocols.
Which common fieldbus protocol platforms does 0G0010.00-090 support?
It is commonly applied within PROFIBUS DP and other standard serial bus networks based on RS485.
